    • Multi-layer FPC(FLEXBOARD)

    FPC=Flexible Printed Circuits　

    “FLEXBOARD” is a multi-layer flexible printed circuit board with nearly unlimited design possibilities.

    Features

    100% Polyimide material construction provides greater thermal reliability than our competitor’s multilayered circuits.

    This functional integration of the flex cable and rigid board eliminates connectors and saves space.

    Basic structure


    Base material
    Polyimide film

    25μm(1mil)、12.5μm(1/2mil)
    Cu

    17.5μm(1/2oz)、12μm(1/3oz)
    Cover material
    Polyimide film 25μm(1mil)、12.5μm(1/2mil)

    Resisit
    Via Through Hole 0.20mm～ IVH 0.15mm～、SVH 0.10mm～
    Surface treatment Gold Plating、OSP、Solder Plating
    Layers 3 to 8 layers

    Special structure 1 【4C1B】

    tasou1

    ※These structures are just examples. More appropriate structures can be provided at your request. Please consult with us individually.

    Special structure 2 【2C2B】

    tasou2

    ※These structures are just examples. More appropriate structures can be provided at your request. Please consult with us individually.
